Rotating Brush Nodule for cleaning printed circuit boards comes in MBK modular construction kit and includes a round brush driven at a fixed speed by a DC motor.

Speed is coordinated to the PCB and the contours. Brush module is mounted underneath the PCB, on the floor of the production cell. By means of height control, the position of the brush as well as the brush wear is monitored. Impurities are removed from the underside of the PCB by the brush and extracted at the same time. Particles of dirt are collected in a catch container. To prevent electrostatic charging of the brush, the module is equipped with an ionization device with discharge head. The ionizing air current is thereby aimed at the brush. Rotation brush, rotation spin and speed are adjustable.

Eutect GmbH

eutect.de
