Master Bond's Supreme 11AOHTLP is a two component epoxy featuring thermal conductivity and electrical insulation.

Features a relatively long working life of 60-90 min. at room temperature for a 100g batch, making it uniquely suited for demanding situations where more time for fixturing is needed. Has reliable electrical insulation properties with a volume resistivity exceeding 1014ohm-cm at 75°F. Also exhibits thermal conductivity of 3-5BTU·in/(ft²·hr·°F) [0.5-0.7W/m/K]. Provides high bond strength properties with a lap shear strength of 3,200-3,400psi, a tensile strength of 7,000-8,000psi, a compressive strength of 20,000-22,000psi and a T-peel strength of 15-20pli. Is designed to withstand thermal cycling and offers a wide service temperature range from -112°F to +400°F (-80°C to 204°C). Cures at room temperature in two to three days, and faster with heat, in 2-3 hrs. at 200°F. Is said to bond well to a wide variety of substrates including metals, ceramics, glass, rubbers, and many plastics.

Master Bond

masterbond.com
