Atlanta, Georgia – Koh Young Technology, the industry leader in True 3D measurement-based inspection solutions and the Premier sponsor of IPC APEX Expo, will deliver live demonstrations of its award-winning inspection and measurement solutions during the live tradeshow in the San Diego Convention Center on January 25-27, 2022 in San Diego, California.

After a lengthy lock-down, Koh Young will embrace the comprehensive safety and hygiene protocols in place to ensure a safe environment for attendees, so that the industry can meet face-to-face. Koh Young will highlight several award-winning solutions at the Koh Young America booth (1717) and the Factory of the Future Pavilion (1701). The following is just a glimpse into what Koh Young will have in store for our visitors.

Solder Paste Inspection (SPI)

In 2002, we introduced the concept of 3D measurement-based solder paste inspection – and it revolutionized the inspection industry. Today, manufacturers recognize the value of the 3D measurement data and use the data to improve the print process, in turn, improving production yield and quality. Today, 3D SPI has become a standard requirement for SMT lines – it is no longer optional. The KY8030-3 is our SPI workhorse, and the most popular SPI solution in the electronics manufacturing market. With a patented dual-projection technology, we deliver trustworthy and repeatable measurement data, which manufacturers can use to reliably optimize the print process.

·         A close-up of a keyboard

Description automatically generated with low confidenceKY8030-3: Industry’s Fastest True 3D SPI Solution with Integrated Auto-Repair Dispenser

·         aSPIre3:  Industry’s Highest Performing True 3D SPI Solution

Printing Process Optimization

The award-winning Koh Young Process Optimizer (KPO Printer) solution is an AI-based automatic print process optimizer. This system improves the printer offset, as well as critical printer parameters like squeegee speed, print pressure, and separation speed. KPO performs an automated DOE to determine the optimum printing parameters for the best print quality. As a result, manufacturers can optimize the print process, without the need for a dedicated print process expert. Furthermore, KPO monitors and perfects parameters in real-time to guarantee quality despite environmental changes.

KPO Printer: Award-winning AI-powered print process control software
Automated Optical Inspection (AOI)

The Koh Young 3D AOI Zenith delivers perfect inspection performance with True 3D measurement technology. In the 2D inspection world, false calls and escapes are unavoidable. To solve this problem, we took a different approach. We based our solution on full 3D measurement technology, not 2D technology and its inherent shortcomings or 2D with some 3D capabilities bolted-on to help. At Koh Young, the Zenith measures all components in True 3D. We find the component body based on true 3D profilometric information. Using this approach, we provide trustworthy inspection results, regardless of component or board color variations. When our 3D measurement data meets artificial intelligence, we can deliver even more advantages to manufacturers.

·         Zenith Alpha: Best Value True 3D Automated Optical Inspection Solution

·         Zenith: Industry’s Fastest True 3D AOI Solution

·         Zenith 2: Revolutionary True 3D AOI Delivering Incomparable Capabilities

·         Meister D: Industry’s Leading Inspection Systems for Advanced Packaging & Semiconductors

Automated Pin Inspection (API)

Built on its world-class True3D™ AOI technology, new enhancements help it break through barriers associated with inspecting products with a mix of both Pins and SMDs. The complete KY-P3 lineup provides an automated back-end solution combining advanced high-resolution optics and innovative AI-powered vision algorithms for single pin, press-fit, and Final Optical Inspection, as well as for pins inside a connector shroud, while also inspecting traditional SMDs on the same product. Because of its quantitative measurement-based approach, accuracy and repeatability is unsurpassed.

·         KY-P3: Industry-awarded breakthrough in 3D Automated Pin Inspection

Dispense Process Inspection (DPI)

The award-winning Neptune is the industry’s first 3D optical measurement solution for transparent material inspection. Using Koh Young LIFT technology (Laser Interferometry for Fluid Tomography), the Neptune delivers non-destructive 3D inspection to precisely measure and inspect fluids – wet or dry. With its Machine-Learning algorithm, the Neptune accurately measures materials for coverage, thickness, and consistency with a user-defined threshold setting. It also identifies bubbles, cracks, and other defects in coating. It also measures underfill, epoxy, bonding, glue, potting, flux, and more to deliver an exact measurement of transparent and translucent materials.

Neptune C+: Multiple Award-winning True 3D In-Line Dispensing Process Inspection (DPI) Solution


Process Control Software

AI-powered KSMART solutions help automate process control, while focusing on data management, analysis, and optimization. It collects data from across the factory for defect detection, real-time optimization, enhanced decisions, and traceability to improve production, increase quality, and lower costs by eliminating variances, false calls, and escapes.

KSMART: Seamless Smart Factory Software Suite Turning Data into Insights


A picture containing text

Description automatically generatedFactory of the Future Pavilion & Technical Poster Session

Koh Young was selected to highlight how it is solving significant business challenges by applying connectivity to modernize industry processes. Across the aisle from our booth, in the Factory of the Future pavilion, Koh Young will discuss how to leverage IPC-CFX with Koh Young AI-powered technologies to help manufacturers realize a smart factory. These tools collect factory data on defects, optimization, traceability, and more to improve metrics, increase quality, and lower costs. Yet, successful CFX implementation on the shopfloor requires confidence that equipment has been qualified to IPC-CFX. In this presentation, we will explore how Koh Young successfully applies real-time data to improve the production process by converting data into process knowledge using CFX and other software tools. Combined with IPC communication standards, the gates to a smart factory are open to anyone. If you cannot make it to the pavilion, grab a drink, lunch, or an ice cream and mingle with Koh Young experts at the poster sessions in booth 3815 to discuss how to use IPC-CFX to enable a smart factory.

To learn more about how our solutions boost your quality, visit us at the IPC APEX Expo in Booth 1717 during 25-27 January 2022 at the San Diego Convention Center in San Diego, California. You can register to attend the in-person conference and exposition at www.ipcapexexpo.org/registration/2022-registration-options.

Koh Young America is excited to reconnect and collaborate in-person, while ensuring COVID safety protocols are implemented and upheld for your health and ours. If you cannot attend the show, you can still learn more about our best-in-class inspection solutions at our regional website www.kohyoungamerica.com.
