Goepel Updates Pilot AOI Software v. 6.7
Pilot AOI system software v. 6.7 is interface for operating 3-D AOI and SPI systems, both for SMD and THT inspection.
Programming processes reportedly have been greatly shortened. Can create and optimize inspection programs using digital twin. A real, assembled board does not have to be available. Project was in cooperation with Siemens Digital Industry software and uses Valor Data Prep Express tool for importing CAD and manufacturing data. Includes MagicClick function. Provides actual component geometry, including height information and individual pin and solder joint position. AOI inspection programs can be created and optimized automatically. Is based on Siemens’ ODB++ process language; is for open exchange of process engineering information between disparate machines and processes; contains essential elements from design data, including detailed part shape definitions and advanced descriptions of production requirements such as alternative part definitions, solder paste apertures, machine support pins, place last guidance and warp detection points.
Goepel
goepel.com
