Sensitive Wire Feed is a process-reliable handling technology for reproducible solder joints with wire-guided processes. Involves a feed module that can be freely integrated and used for all applications in assembly and interconnection technology and can be combined with different process modules. Helps ensure reproducibility and process reliability during piston and laser soldering. For applying a specific amount of solder when piston, laser, or induction soldering.
Works by feeding wires to process surfaces in a path- and force-monitored manner. The wire's impact force can thus be defined. Wire feed is stopped when this is achieved. Both feed and withdrawal of wire are monitored. Wire kinking is avoided using this function; component and handling tolerances are compensated or detected. Reference points are likewise specified here in order to be able to transport controlled, reproducible amounts of wire. Wire-reel holder is aligned flexibly so that various wire-reel positions as well as reel diameters can be used in the shortest possible time. Work angle can be freely selected. Wire is stably introduced into soldering process in a regulated manner using intelligent sensor technology. C6 controller records all process steps, enabling 100% data capture.
Eutect, eutect.de
Sigma F8S component placement machine delivers an average 5% improvement in productivity (takt time) over previous F8 models and is more durable. Features improved x-y axis using new linear motor technology, and achieves lower vibration through weight reduction and adoption of cancellation-type linear motors.
Yamaha Motor IM, visit www.yamaha-motor-im.com
VectraES wave soldering machine includes patented UltraFill wave nozzle design capable of changing between air and nitrogen by recipe, precision selective fluxing, convection and IR preheat available in any position and/or location. Features new full N2 tunnel.
Speedline Technologies, speedlinetech.com
Electrovert OmniES+ full convection reflow oven comes in 5, 7, 10, and 13 zones. Uses patented IsoThermal chamber technology. Includes independent blower control in each heating and cooling zone, uses up to 36% less power than competitive systems, patented dripless cooling, and closed loop N2 control capable of maintaining inert atmospheres of <50ppm.
Speedline Technologies, speedlinetech.com
CM+ series contaminometers measure the amount of ionic contamination in accordance with all existing test methods (ROSE; process ionic contamination testing or PICT). Is freestanding and accommodates larger assemblies while maintaining a low surface area to test solution ratio. Uses solid gold test-cell, ballistic amplifiers and vigorous pumping systems to ensure measurement precision even at low conductivity values. PC-based software outputs graphical test data, pass/fail analysis and automatic hard copy. Also feature high-speed testing in 3 min.; full regeneration in typically
Gen3 Systems, www.gen3systems.com
TS9300HM Series Pur Hot Melt Jet Valve and TS930 controller are designed for high-temperature operation. TS9300HM series features diaphragm technology. Replaceable diaphragm reportedly eliminates dynamic fluid seals. Only nozzle plate and diaphragm contact fluid. TS9300HM syringe heater features disposable feed tube. Has thermal jacket designed around feed tube. Controller offers fluid management and standalone or remote control operation. PID auto-tuned temperature controllers with RTD sensors maintain uniform temperatures up to 150°C. Includes dual independent temperature controllers for jet and syringe heater. Dual trigger mode enables valve to dispense single drops, multiple drops and lines.
Techcon Systems, www.techconsystems.com
