In-Sight Micro 8000 series cameras are ultra-compact, standalone vision systems with PC speeds. Use In-Sight Explorer software with EasyBuilder setup. Include PatMax RedLine technology. Measure 31 x 31 x 63mm and include Power over Ethernet, minimizing cabling. Are for integrating into tight spaces on robots and hard-to-reach machinery. Can be deployed almost anywhere on production line for guidance, inspection, gauging and industrial identification applications.

Cognex, www.cognex.com/In-SightMicro8000

Supreme 18TC is a single-component epoxy adhesive that contains thermally conductive fillers. Can be applied in bond lines as thin as 10 to 15µm. Offers thermal resistance of 5-7 x 10-6 K•m²/W and a thermal conductivity of 22-25 BTU•in/ft²•hr•°F [3.17-3.61 W/(m·K)]. Reportedly maintains high bond strength properties when exposed to hostile environmental conditions, including high or low temperatures. Bonds well to metals, composites, ceramics and plastics. Offers tensile lap shear strength of 2,200-2,400 psi, a tensile strength of 6,000-7,000 psi, and a compressive strength of 22,000-24,000 psi. Is a one-part system that doesn’t require mixing. Requires heat curing for 60-90 min. at 250-300°F. A post-cure of a few hours at 350°F optimizes performance properties. Features low shrinkage upon curing, low CTE and high degree of dimensional stability. Is a reliable electrical insulator. Is designed to withstand thermal cycling and shock. Is serviceable over the temperature range of 4K to +400°F. Passes NASA low outgassing tests.

Master Bond, www.masterbond.com

Versaflow 4/55 inline selective soldering system features motorized adjustable y-axis for fluxer- and solder module, y- and z-variability, full convection preheater and a 508 x 508mm usable process area for inline production.

MSA401L-1 1ml manual syringe assembly consists of barrel, plunger and piston all fully assembled without any lubrication. Provides simple and quick dispensing without need for compressed air. Barrel and plunger are made from polypropylene resin; piston is made from thermoplastic rubber. Comes in bulk package of 1000 pieces.

Techcon Systems, www.techconsystems.com.

Third generation BF-3Di-D (dual lane) and BF-3Di-Z (extra-large platform) 3D AOI equipment provide measurements of components with a height range between 0 and 20mm, achieving 1µm height resolution, a false call rate of less than 100ppm with zero escapes, with an increased positioning speed of 50%. New camera and lighting systems reportedly capture clear, detailed images with no shadowing for inspection of lifted leads, tombstones, reverses, and height variations.

Saki Corp., www.sakicorp.com
