Tilt Table platform permits the subject under inspection -- a populated PCB -- to be rotated 360 degrees in combination with up to 30 degrees of tilt, affording side views of device packages, legs and solder joints. Incorporates a large spherical joint for durability and stability. The 250mm diameter platform comes with adjustable PCB holders and an ESD-protected non-slip mat to safely maintain desired position, leaving hands free for other tasks. Optional electromagnetic position lock for heavier objects or when an optimum fixed position is required.

Optilia, www.optiliaindustrial.eu

Quicky 300 vapor phase soldering machine is for laboratory and single piece production. Process zone with lift unit and workplace carrier is integrated in the self-supporting structure. Includes sensors for heaters, fluid and vapor temperatures. Handles solder format up to 300 x 300mm, and 60mm height. Processes lead and lead-free product. Runs on a 240V power supply.

Asscon, www.asscon.de

Eazycoat multi-axis coating system is a robotic conformal coating application platform for low- and medium-volume batch and inline processing. Comes with programmable software and stepper motor process control. Slides on XYZ axes. XYZ repeatability and resolution is 50 microns (0.01").

EPS, www.eps-ww.com

WSM 310 wave soldering machine has with finger conveyor for boards up to 11.8" (300mm). Self-contained fluxing, preheating, and laminar (smooth) solder wave modules. Optional turbulent (SMT passive) solder wave module available. Streamlined design, for easy maintenance and cleaning. Welded steel frame. On-board profiler. Is lead or lead-free compatible. Solder pot trolley system offers quick changeover. Single or dual wave compatibility.

EPS, www.eps-ww.com
