Adjust-a-Vac vacuum tweezer is for handling very thin/delicate substrates, wafers, MEMS devices and other fragile components. Can adjust vacuum level from 1-10" of mercury. Integrated 10-segment bar graph display shows vacuum level present during operation. Bar graph shows minimum vacuum pressure until part is grasped, then displays vacuum level presented to the part being handled. Vacuum port integrates a user-replaceable inlet filter.
Virtual Industries, www.virtual-ii.com
Master Bond MasterSil 912Med is a room temperature vulcanizing silicone system for bonding, sealing and coating. Meets USP biocompatibility and ISO cytotoxicity standards and resists a variety of sterilization techniques such as gamma radiation, EtO and some types of liquid sterilants. A one-part material offers noncorrosive cure with a tack-free time of 15-30 min. at room temperature. Translucent color; serviceable over temperature range of -75°F to +400°F. Tensile strength 700-1,100 psi. Adheres to metals, composites, ceramics, glass, rubbers, plastics and other silicone substrates. Elongation 250-350%. Volume resistivity of >1015 ohm-cm. Comes in 80g tubes and has a shelf life of 6 months.
Master Bond, masterbond.com/tds/mastersil-912med
Laser shape rings aid selection of optimal laser spot shape to fit components and land shapes to reduce circuit board problems. Come in twin-spot, circle, square, ring and oval ring. Help avoid inadvertent burning of PCBs. Twin-spot enables simultaneous soldering of two joints.
Japan Unix, japanunix.com/en/products/laser/shapes.php
• Verification video showing how incorrect laser shapes burn components: youtube.com/watch?v=iqjpVepqWbU
• Twin beams working two components simultaneously: youtube.com/watch?v=vRWr80bnCfg
Pressure-Sensitive Cover Tape 2698 transparent, polyester film tape has synthetic, room-temperature, pressure-sensitive adhesive zones at its sides. Helps eliminate pick-and-place errors, minimize down-time and increase productivity. Is said to enable near-flawless placement of chips on circuit boards without sticking, static charge or contamination. Comes in standard widths and 600m reels designed to reduce changeover time and enable productivity improvements. Compatible with existing industry-standard equipment.
3M, http://www.3m.com/transport
THT-Line AOI for double-sided inspection of plated through-hole assemblies now comes with tape transport in addition to roller conveyor for work piece carriers. Inspects selective solder joints on assemblies transported without work piece carrier. Can be used both for actual manufacturing process in the upper area of the system as well as return transport in lower area of the machine. Also has laser measuring system for coplanarity control (e.g., for connectors) or for height measurements on various components. Up to two different and independently operating AOI modules can be integrated into a single system chassis.
Goepel Electronics, www.goepel.com
EMS 618-15 is a room temperature cure two-part conductive adhesive for printed circuit board assembly applications. Is said to cure in 24 hr. at room temperature or rapidly at elevated temperatures. Has a 10-to-1 mix ratio and comes in a two syringe package designed for use with static mix heads. Forms high-strength, high-reliability conductive interconnects.
Engineered Material Systems, www.emsadhesives.com
